The Dynacord C3600FDi C-Series FIR-Drive Power Amplifier is a 1800W audio amplifier designed for permanent installation applications, to provide background or live music in venues including bars, houses of worship, restaurants, sports facilities, and performing arts centers. The C3600FDi is equipped with a robust power supply and a powerful linear amp design, well suited for the most demanding environments. The sophisticated protection circuitry ensures safe, reliable operation under all conditions. The amplifier is also suitable for direct drive applications with 70/100V speaker lines for a variety of flexible install scenarios.
The C3600FDi features Euroblock connectors for convenient wiring, remote power-on delay, and GPIOs to interface with third-party controls. An efficient standby power mode reduces running costs and power consumption by up to 90%, leading to a low cost of ownership. The amplifier utilizes high-quality components throughout for truly professional processing power and performance characteristics. The on-board DSP includes multi-band PEQs (parametric EQ), crossovers, limiters, and delay per channel. It also has true channel grouping control with extra DSP capabilities like PEQ, GEQ (graphic equalizer), and delay for each group. The Dynacord C3600FDi ships with a power cord, USB cable, and a variety of Euroblock & power remote connectors.
Installation DSP amplifier, Euroblock connectors
Fully integrated professional speaker processing with FIR Drive technology
Professional acoustic performance and rock-solid reliability
Low-Z and 70/100V operation and power saving standby mode
Powerful and proven audio performance
Engineered for constant stability at 2 Ohms
Low- and high-impedance outputs and remote GPIO control
Highly efficient standby power mode reduces running costs and power consumption up to 90%
Sophisticated protection circuitry always protects the amplifiers and connected loudspeakers
High-performance bulletproof voltage handling
On-board DSP includes multi-band PEQs, crossovers, limiters and delay per channel; True channel grouping control with extra DSP capabilities including GEQ
Intuitive, powerful control software makes configuration and real-time control easy. Up to 16 amp channels can be controlled and monitored simultaneously
Advanced FIR drive to optimize loudspeaker settings, providing premium features into an installation form factor
Engineered in Germany
In the Box
Dynacord C3600FDi C-Series FIR-Drive Power Amplifier 3600W
Power Cord
USB Cable
6-Pin Euroblock GPIO Connector
4-Pin Euroblock Output Connector
2 x 2-Pin Euroblock Input Connectors
2-Pin Power Remote Connector
Limited 3-Year Warranty
Load Impedance
2 Ohms
2.7 Ohms
4 Ohms
8 Ohms
Maximum Output Power
Single Channel
2 Ohms: 3200 W
2.7 Ohms: 2700 W
4 Ohms: 1800 W
8 Ohms: 950 W
Dual Channel
2 Ohms: 3000 W
2.7 Ohms: 2500 W
4 Ohms: 1700 W
8 Ohms: 900 W
High-Impedance 70 V: 2 x 1250 W
High-Impedance 100 V: 2 x 2500 W
Bridged
4 Ohms: 6000 W
8 Ohms: 3400 W
Impedance
High-Impedance Operation: 70 V, 100 V
Maximum RMS Voltage Swing
90.6 V
Voltage Gain
32.0 dB (ref 1 kHz)
IMD SMPTE
IMD-SMPTE, 60 Hz, 7 kHz: < 0.1%
DIM 30
< 0.05% (3.15 kHz, 15 kHz)
Maximum Input Level
+21 dBu
Crosstalk
< -80 dB (ref. 1 kHz, at 100 W / 4 Ohms)
Frequency Response
10 Hz to 21 kHz (±1 dB)
Input Impedance
20 kOhms
Signal-to-Noise Ratio (SNR)
> 109 dB (A-weighted)
Output Noise
< -68 dBu (A-weighted)
Total Harmonic Distortion
< 0.05% (at 1200 W / 4 Ohms MBW = 80 kHz, 1 kHz)
Topology
Class-H
Signal Processing
FIR filters
Audio limiters
Output delay per channel
31-band GEQ per channel
PEQ per channel
Load impedance
Protection
Audio limiters
High temperature
DC
HF
Back-EMF
Peak current limiter
Inrush current limiters
Turn on delay
Cooling
Front-to-rear, 3-stage fans
Safety Class
I
Color
Black
Operating Temperature
40 to 105°F / 4 to 41°C
Power
Power Requirement: 120 VAC, 60 Hz
Power Consumption: 850 W (1/8 maximum output power @ 4 Ohms)
Mains Fuse: T30AH
Dimensions
3.5 x 19.0 x 18.2″ / 88.9 x 482.6 x 462.3 mm
Weight
40.1 lb / 18.2 kg
